Veneer Double Knife Clipper machine CQ3400 China Woodworking Machine Manufacturer
The Veneer Double Knife Clipper machine is equipped with a laser safety light curtain to ensure the safety of use. Once the safety light curtain senses your hand, the equipment will immediately stop working.
Description
| Model | CQ3400 |
| Max. Cutting length | 3400mm |
| Cutting width | 30-450mm |
| Front knife size | 3470mm |
| Rear knife size | 3420mm |
| Power | 10kw |
| Air pressure | 0.5mpa |
| Max. pressure | 10mpa |
| Min. Cutting width | 30mm |
| Weight | 8500KG |
| Dimensions | 4930*2000*1900mm |
Characteristic:
- The shearing knife is made of high-speed steel, effectively extending its service life
- The equipment is equipped with a laser safety light curtain to ensure the safety of use. Once the safety light curtain senses your hand, the equipment will immediately stop working.
- The equipment has both manual cutting mode and automatic cutting mode. The operation is more flexible and convenient.
- The front knife, rear knife and pressure beam are all controlled by a hydraulic transmission system, which can adjust the pressure in a timely manner to meet the needs of various veneer veneers, and at the same time ensure that the two knives can cut simultaneously.
- The workbench adopts precise and robust parallel linear guides and ball screws, combined with servo motors to ensure shearing accuracy and parallelism.
