Edge Banding Machine HZH368E
Edge Banding Machine with ideal system with ease and precision for panel edge banding, MDF, particle board, OSB, solid wood, and aluminum honeycomb etc.
Description
Edge Banding Machine with Stable bedframe which is manufactured by a rigid foundation, with superior welding, CNC machining, tempering and painting process.
| Model | HZH368E |
| Edge thickness | 0.4-3mm |
| Work piece thickness | 10-55mm |
| Panel length | >120mm |
| Panel width | >55mm |
| Feeding speed | 18-22m/min |
| Pre-milling power | 2.2kw*2 |
| Heating power | 2.6kw |
| Glue power | 0.75kw |
| End cutting | 0.37kw*2 |
| Rough milling | 0.75kw*2 |
| Fine milling | 0.75kw*2 |
| Corner trimming power | 0.37kw*2 |
| Buffing | 0.37kw*2 |
| Conveyor belt | 4kw |
| Lifting power | 0.37kw |
| Total power | 17.3kw |
| Working pressure | 0.6Mpa |
| Outline size | 6700*1000*1600mm |
| Net Weight | 2500kg |
