Double Side Sanding Machine MM5813
Double side sanding machine is mainly applied in calibrating and fine-sanding particleboard, block board, MDF, high-pressure overlaying board, multi-layer, cement particleboard, medium or high density calcium silicate board and solid wood etc.
Description
| Model | MM5813R-R |
| Sanding units | 4 |
| Working width | ≤1300mm |
| Working thickness | ≤100mm |
| Working length | ≥900mm |
| Working precision | ±0.08mm |
| Sandpaper size | 1350*2560mm |
| Speed of sandpaper | 25m/s |
| Feeding speed | 8-25m/min |
| Front unit Roller diameter | Φ276mm |
| Rear unit Roller diameter | Φ276mm |
| front unit motor power | 75Kw*2 |
| rear unit motor power | 55Kw*2 |
| Feeding motor power | 15kw |
| Lifting motor power | 2.2kw |
| Brush roller motor | 0.75kw*2 |
| Working air pressure | 0.6Mpa |
| Volume of dust-collecting | 56000m³/h |
| Speed of dust-collector | ≥25m/s |
| Working production line height | 1450mm |
| Weight | 20T |
| Dimension | 3100x2700x3120mm |
The double side calibrating sanding machine series is unlimited by the original thickness tolerance. It is significant for the woodworking machinery to calibrate the wood-based panel and get the required thickness and precision through double-side sanding.
Applications of Double Side Sanders
1. Woodworking Industry
In the woodworking sector, double side sanders are essential for processing panels, boards, and other wooden materials. They ensure uniform thickness and smooth surfaces, making them ideal for preparing components for further finishing processes such as veneering, lacquering, or painting.
2. Furniture Manufacturing
Furniture manufacturers utilize double side sanders to achieve high-quality finishes on tabletops, chair seats, and other components. The machine’s ability to sand both sides at once saves time and labor costs while ensuring consistency in surface smoothness.
3. Cabinet Production
In cabinet production, precision is crucial. Double side sanders help achieve accurate dimensions and smooth surfaces for cabinet doors and frames. This ensures that all parts fit together seamlessly and enhances the overall aesthetic of the finished product.
4. Composite Material Processing
Double side sanders are also effective for processing composite materials like MDF (Medium Density Fiberboard) and particleboard. These materials often require sanding to remove rough edges and prepare them for assembly or lamination.
5. Automotive Industry
In the automotive sector, double side sanders are employed for smoothing and shaping parts made from various materials, including plastics and metal. They play a crucial role in ensuring that components meet specific tolerances and surface finish requirements.
6. Glass and Metal Finishing
Some advanced models of double side sanders are used in glass and metal finishing applications. They can polish and smooth these materials, providing a clear finish that is crucial for aesthetic and functional purposes.
7. Production of Decorative Panels
Double side sanders are widely used in the production of decorative panels, allowing for intricate designs and patterns to be achieved with a smooth and even surface that enhances the final appearance.
8. Prototype Development
In prototype development, where precision and experimentation are key, double side sanders allow for quick adjustments and refinements to be made on both sides of a prototype, facilitating faster iteration cycles.
