It adopts laser ranging, precise docking (docking error ±0.3mm), high accuracy.
Curve Edge Banding Machine make the trimming area no damage the surface of the product and can improve the appearance quality of the product. With a cleaning device, the board will be cleaner.
Curve Edge Banding Machine make the trimming area no damage the surface of the product and can improve the appearance quality of the product. With a cleaning device, the board will be cleaner.
| Model | FB715 |
| Edge belt thickness | 0.5-3mm |
| Edge belt width | 15-50mm |
| Work piece radius | 150-1200mm |
| Min curve working radius | 20mm |
| Feeding speed | 0-11m/min |
| Total Power | 3Kw |
| Heating power | 1.6Kw |
| Working air pressure | 0.55mpa |
| Overall dimensions | 1600*1400*1800mm |
| Package size with plywood case | 1800*1700*1500mm |
| Weight | 480Kg |
| Voltage | 380V 50Hz |
Curve edge banding machines are widely used in various industries, especially in furniture and interior design.
Some key applications include:
Furniture manufacturing: Curve edge banding is often applied to furniture pieces such as tables, chairs, and cabinets. The machine helps achieve a high-quality, polished finish for the edges of curved wooden surfaces.
Cabinet making: In the production of curved cabinets or kitchen islands, edge banding machines ensure the edges are smooth and protected.
Interior design: For curved wall panels, partitions, and custom-designed furniture, curve edge banding machines provide a neat finish that complements the design.
Woodworking: Carpenters and woodworkers use these machines to apply edge banding to various wood products, such as curved panels, doors, or custom wood pieces.
Retail and display units: Curve edge banding machines are also used to produce attractive, durable edges for custom displays and retail fixtures.
Boatbuilding: In boat construction, where curved wooden surfaces are common, these machines help create smooth, waterproofed edges for the exterior and interior of boats.
