Veneer Splicer Stitching Machine ZP2000D
Veneer splicer stitching machine,suitable for furniture table, kitchen cabinet panel, door skin, decorative panel of solid wood sheet stitching. Changing the traditional car stitching machine, the straight single board wireless sheet stitching machine uses special heating and feeding mechanical structure splicing, so that the wood sheet can be closely combined and stitched without gap. It can effectively improve work production efficiency, reduce back sanding and reduce costs.
Description
| Model | ZP2000D auto glue spreader |
| Splicing thickness | 0.3-2mm |
| Splicing length | ≥350mm |
| Splicing speed | 0-45m/min |
| Rated air pressure | 5kg |
| Rated power | 6.5kw |
| The moisture concent of wood veneer | 8-16% |
| Votage | 380v |
| Weight | 1650kg |
| Dimension | 2200*2000*1600mm |
Characteristic
- Veneer splicer machine is processed and formed by CNC, with high precision and not easy to deform. The pneumatic
components use imported high-precision proportional valves, ensuring stable brand use and longer
service life.
- The conveyor chain is formed using imported special material molds, which have good flatness, wearresistance and high temperature resistance, and do not produce blue stains.
- The whole machine is equipped with a microcomputer numerical control system. To change the
thickness of the wood veneer, simply select the corresponding wood veneer thickness parameter and automatically adjust the required pressure. It can save 100 types of wood veneer parameters.
- Built in automatic glue coating system, no overflow, easy to clean.
- An additional automatic cooling system delays the use of glue.
